Key attributes
Other attributes
Place of Origin
Anhui, China
Brand Name
IROAD
Application
Pedestrian Safety Remind
Shape
Shapes Customized
Size
Customized
Color
Customized Color
Feature
Reflective+ LED Light
Power supply
Solar Power+Main Supply
Keyword
Aluminum Sign
Sample
Freely Provided
Warranty
3Years
MOQ
1PC
Packaging & delivery
Package Type:
CARTON , WOODEN CASE
Supply Ability
Supply Ability
500 Set/Sets per Month
Product details
Product Description
Specification
| Work temperature | -40-50 °C |
| Alloy pressing die | Side length≤900mm，Diameter≤800mm |
| Shell material | Aluminium |
| Tensile yield strength | ≥ 60MPa |
| Shore hardness | ≥80D |
| Luminousness | ≥85% |
| Bending strength | ≥60MPa |
| Shell weight | ≤22KG/m2 |
| Entire thickness | ≤ 60 mm |
| High light transmission typemicroprism reflective film | white luminousness ≥25% |
| Uniformity of light transmission | 1.2:1-1.31 |
| LED bright | White≥300cd/㎡, yellow≥150cd/㎡,red≥45cd/㎡, |
| green≥45cd/㎡,blue≥30cd/㎡, brown≥22cd/㎡ | |
| High light transmittance microprism reflective film | White transmittance ≥25% |
| Resin material circuit board | 1.2*400*800mm |
| Power consumption | 200Mw |
| Forward current, | 20mA |
| Reverse voltage | 6V |
| Visual distance | ≥210m(Day time) |
| ≥250m(Night time) | |
| Luminous flux | 8.0-9.0lm |
| Luminous direction angle | 120Deg |
| Solar panel | 24V/24V |
| Power network | 220V/24V |
| Duration time | ≥120h |
| Long life | 7-10 years |
| Warranty | 3 years |
